SOLID STATE SECURITIES SS90 - ELECTRICAL AND MECHANICAL CHARACTERISTICS; OPERATING VOLTAGES; CURRENT REQUIREMENTS; INITITIATING LOOPS

TROUBLE RELAY (TB1-8,9&10) The trouble relay toggles immediately upon a power loss or alarm condition and may be
used for turning on signalling appliances (horns,strobes,etc.) or other external signalling functions requiring a dry contact
open or closure. Figure 4 illustrates contacts with no power to unit. With power applied TB1-9&10 are closed and toggle in
alarm and power loss.
Optional wiring - Verify that all operating voltage is off before continuing.
5. Normally open lower limit/proximity switch (closes in down limit). Connect wiring from *Aux. electrical loop to
TB1 screws 5 & 6. Leave jumper in TB1-6&7. Remove jumper & use TB1-6&7 for a N/C which opens in down limit.
6. Trouble Relay - Connect wiring to common TB1-9 and either N/O contact TB1-10 or N/C contact TB1-8.
* Note: Electrical loop must be provided as dry contacts and may not be used in conjunction with the simulta-
neous switching of a motor control or any other voltage through the same contacts. Connections of this type will
result in immediate damage to the release device.
Verify all connections made within unit. Close hinged cover and secure screw on lid after all connections are made.
DO NOT LEAVE COVER OPEN AFTER CONNECTIONS ARE MADE!
"SS90" SERIES RELEASE DEVICE ELECTRICAL AND MECHANICAL CHARACTERISTICS
OPERATING VOLTAGES
MODEL
SS90A-WPS ............. 24VDC +10% /-15% 24VAC +10% /-15% 120VAC +10% /-15%
SS90B-WPS ............. 24VDC +10% /-15% 24VAC +10% /-15% 120VAC +10% /-15%
CURRENT REQUIREMENTS
-------------------------------- Operating Voltage ---------------------------------
24VDC 24VAC 120VAC
Current rating SUPERVISORY/ALARM SUPERVISORY/ALARM SUPERVISORY/ALARM
Model
SS90A-WPS .025A/.045A .075A/.130A .300A/.650A
SS90B-WPS .025A/.045A .075A/.130A .300A/.650A
INITIATING LOOPS -
CAUTION: All initiating devices shall be dry contact type only
Maximum loop resistance: 100 Ohms
Maximum current: Not to exceed .002A
Maximum voltage: 15Vdc
FORM C OUTPUT (MAXIMUM CONTACT RATING) FUSE RATINGS
2A/15Vdc 30 Watt DC Resistive Load Only Model A/B PC Board - 0.75 AMP @250V
2AG FAST ACTING TYPE
3
WPS PC BOARD
F1 2A @ 250v, 2AG Fast Acting, high voltage input
F2 1A @ 250v, 2AG Fast Acting, low voltage input
F3 1A @ 250v, 2AG Fast Acting, low voltage output
MECHANICAL- LOAD RATING DIMENSIONS
Support and release: 40LB. MAXIMUM 7 1/2" x 8 " x 4" (H x W x D)
