SECTION D. TEST PROCEDURES
TO BE PERFORMED BY FACTORY AUTHORIZED PERSONNEL ONLY! SOLID STATE SECURITIES
RECOMMENDS REGULAR TESTING OF ALL RELEASE DEVICE EQUIPMENT. TESTING SHALL BE
WITNESSED FOR PROPER OPERATION.
Follow step A for electronic testing of Model SS90-A-WPS. Step B refers to Model SS90-B-WPS with Close Limit option.
Step C power loss test may be performed on both models A and B. Testing does not affect normal operation of alarm system
when connected to release device. Testing and normal operation can only be accomplished with power applied to unit.
When power is applied to unit under test the Power LED (red) will be lit on the bottom of the release device. Testing of the
"SS90" release device is independent of, and shall in no way be interpreted as an alternative method of, testing of the
fire alarm system, motorized operator and/or any other system component employed on the fire door or counter fire
door installation.
CLEAR FIRE DOOR OPENING AND PROHIBIT ALL TRAFFIC THROUGH DOOR OPENING DURING
TESTING OF SYSTEM!
Door must be in open position with power applied to unit to begin testing.
A) 1. Depress and continue to hold test button on side of release device (figure 1). After factory adjusted 10 second
alarm verification (10 sec. delay) device will release door. Release test button.
2. Reset and raise door, then reset release device by pushing reset lever in direction of arrow as indicated on device
label. Fully insert end link through release device side opening and release reset lever to latch end link.
B) 1. Using chain hoist, lower door to fully closed position.
2. Reset door, then release device by pushing reset lever in direction of arrow as indicated on device label. Fully
insert end link through release device side opening and release reset lever to latch end link.
3. Verify that Close Limit LED (amber) is lit indicating “the door is closed”. Depress and continue to hold test
button on side of release device for 10 seconds. Active ”Lower Limit” logic will prohibit the release device from
energizing. Release test button.
4. Raise door to fully open position.
C. Power Loss Test.
1. Make sure door is in the fully open position. Turn off “all” power to release device (including motor control
voltage when used on the model B). After approximately 10 seconds of continuous power loss, a mechanical
release will be initiated.
2 Reset and raise door, then reset release device by pushing reset lever in direction of arrow as indicated on device
label. Fully insert end link through release device side opening and release reset lever to latch end link.
After completing all tests, make sure door is in its normally open position and all power required for normal
operation is restored to unit. This unit is designed to operate with power applied.
REMINDER:
Testing of the "SS90" release device is independent of, and shall in no way be interpreted as an alternative method
of, testing of the fire alarm system, motorized operator and/or any other system component employed on the fire door
or counter fire door installation. TESTING SHALL BE PERFORMED AND WITNESSED FOR PROPER
OPERATION.
4
