Solidremote 202U - Details Explanation; Setting Relay Operation in True Latching Mode

Visit solidremote.help if you need help
ALWAYS post a new topic in forum & double check email for prompt response, thanks.
--- Page
4
settings by using PRG1 Details Explanation
PRG1 & DIP Switch 1
Controls pulse / momentary mode delay
The delay period can be observed by press transmitter button to activate relay in pulse mode, then release transmitter button.
The relay hold on period between transmitter button release  relay release is the delay.
The default value is 0.5s for well balance between fast response and high stability.
When you set to 1s, the perceived relay stability during pulse mode will be better, while the response speed for relay release is slower.
PRG1 & DIP Switch 2
Controls whether to turn on uninterruptible timed mode UTM
When uninterruptible timed mode (UTM) is ON, receiver will refuse to take any command when at least one relay channel’s timer is currently
counting down (relay is still activating).
When UTM setting is OFF, you can restart timer or cancel timer (turn off both relays) at any time.
✔ Above setting affects timed output mode ONLY (when DIP 3 is ON position, in normal working)
PRG1 & DIP Switch 3
Switch between standard and extended true latching working mode
True latching mode enables you to control each relay latching on/off independently (as opposed to interlock latching mode).
When this setting is OFF, our receiver is in standard mode, and the working mode settings can be seen on Page 1 of this manual Setting Relay
Operation in Standard Mode
When setting is ON, our receiver is in true latching mode, the working mode has been changed to below.
Setting Relay Operation in True Latching Mode
DIP Switch 1 ON ON OFF OFF
DIP Switch 2 ON OFF ON OFF
↓
Relay 1 Hold
True Latching

Pulse
Relay 2
Reserved
True Latching

True Latching

True Latching


To turn off relay 1 in this mode, press the special function button which is assigned to both relays 1&2 (programmed by press both PRG1
& PRG2 buttons during storing transmitter code).

To turn off relay 2 in these modes, press the special function button which is NOT assigned to any relay (the specific button is not
assigned to any relay, but at least one other button on the same transmitter should be assigned to any relay).
✔
This setting does NOT affect timed output mode.
