121120
GB GB
A B C D
E
N
M
K
L
J
H
I
G
F
U
W
V
S
T
O
Y
Z
Q
P
R
X
s
APPLIANCE DESCRIPTION
A Programming button “Prog.”
for programming the settings
B Coffee extraction button for 1 cup
C Coffee extraction button for 2 cups
D Steam button
E Pressure gauge (manometer)
F Brewing group with brewing head
G Drip grid, removable
H Drip tray, removable, with inlying red float gauge to indicate when the drip
tray is full.
I Moveable steam / hot water wand, with thermo-insulated handle and
removable steaming nozzle
J Cup tray
K Water tank lid, removable
L 1,7 litre water tank, removable, with Min- and Max-markings, handle and
filter cartridge bracket
M Steam / hot water control
N
;
ON / OFF button
To turn the espresso machine on and off
■
ACCESSORIES
O Single-wall filter for one cup (54 mm)
P Single-wall filter for two cups (54 mm)
Q Double-wall filter for one cup (54 mm)
R Double-wall filter for two cups (54 mm)
S Filter for compact 44 mm pods
T Portafilter with double outlet (removable)
U Stainless steel milk jug, capacity 350 ml
V Tamper
W Measuring spoon
X Cleaning tool and cleaning brush
Y Rubber insert for brewing group cleaning
Z BRITA INTENZA water filter cartridge with test strip
