6 Specification and special accessories / 7 Wearing parts / 8 Warranty
ENGLISH 12
6 Specification and special accessories
Model 461 462 463
Spraying agent tank:
Nominal volume ("Total Vol."
1
), approx.
Max. fill volume ("max. Vol."
1
), approx.
8.3 l [2.19 gal]
5.0 l [1.32 gal]
9.5 l [2.51 gal]
7.0 l [1.85 gal]
12.5 l [3.30 gal]
10.0 l [2.64 gal]
Residual volume
not properly discharged by the device
< 200 ml [6.8 oz]
Max. permissible operating pressure ("P max."
1
) 3.0 bar [44 psi]
Permissible operating temperature ("T max."
1
) 0
ccessories: Nozzle kit Part no. 49 00 574
Maximum delivery ("max."
1
)
(with standard spray nozzle at 3 bar)
1.6 l/min [0.423 USgal/min]
Filter element: Mesh aperture
Part no.
0.8 mm [0.031"]
40 74 922 25
Weight (ready for operation):
Spraying agent tank empty
Spraying agent tank filled to max.
1.5 kg [3.3 lbs]
6.5 kg [14.3 lbs]
1.7 kg [3.8 lbs]
8.7 kg [19.2 lbs]
1.9 kg [4.2 lbs]
11.9 kg [26.2 lbs]
Dimensions: Height
(without spray tube Width
and pressure hose) Depth
460 mm [18.1"]
200 mm [7.9"]
200 mm [7.9"]
520 mm [20.5"]
200 mm [7.9"]
200 mm [7.9"]
605 mm [23.8"]
200 mm [7.9"]
200 mm [7.9"]
1
Inscription on the spraying agent tank
7 Wearing parts
Various parts are subject to application-specific
wear or to normal wear and must be replaced in
good time if necessary.
The following parts are subject to normal wear and
are not covered by the manufacturers guarantee:
All rubber parts that come into contact with the
spraying agent
Spray nozzle
Filters
Seals
8 Warranty
We warrant problem free quality and will cover the
cost of replacing parts which are found to be faulty
in material or show manufacturing defects within
the prescribed guarantee period after the date of
purchase.
Please note that specific guarantee conditions may
differ from country to country. When in doubt,
please ask the vendor of the goods. The vendor of
the product is responsible for guarantee
applications.
We hope you will understand that we cannot be
liable for damage resulting from these causes:
Non-compliance with operating instructions.
Neglecting required maintenance and repair
jobs.
Wear from normal use (particularly: gasket
seals, membranes, collars, spray nozzles and
filters).
Using non-approved tools.
Use of force, improper treatment, misuse and
accidents.
Attempted adjustments and repairs by non-
qualified persons.
Unauthorized modification or changes made to
the device.
Use of unsuitable spare parts or non-original
parts if such parts are the cause of the damage.
Use of non-approved media in the spraying
agent tank.
Damage caused by using the product in the hire
or rental industry.
Normal cleaning, adjustments or maintenance jobs
cannot be claimed as part of the guarantee.
All guarantee work must be carried out by one of
our authorised service centres.
