Important Components
ENGLISH 4
1. Important Components
1. On/Off Switch 11. Carburetor Adjustment Screws
2. Throttle Lever 12. Vibration Absorbing Springs
3. Speed Lever 13. Quick-Release Carrying Strap
4. Primer 14. Carrying Strap
5. Choke Lever 15. Carrying Frame
6. Air Filter Cover 16. Pleated Elbow Tube
7. Fuel Tank Lid 17. Blower Tube I
8. Starter Handle 18. Extension Tube II
9. Spark Plug 19. Curved Nozzle Tube
10. Muffler 20. Blower Housing
21. Plug ( Note: This is where, when converting the equipment into a sprayer, the liquid container is connected )
Fig. 1
