Solo 546 - Control and Function Elements; Key Component Identification

Standard delivery; Control and function elements
ENGLISH 4
1. Standard delivery
• Lawn mower
• Grass catching device complete with frame and carrying handle
• Charger, Ignition keys (only with 546RS)
• Spark plug wrench
• Owners manual, owners manual for engine
2. Control and function elements
Adhesive labels:
A Model 546, 546-60: To stop the engine Î release bow handle (1)
Model 546R, 546HR, 546RS: To start the self-drive Î pull bow handle (2) against the tubular handle
To stop the engine Î release bow handle (1)
B
Fill the engine with oil before taking the machine into use
C
Never place the lawnmower on its side
Fig. 1
546
