Control and function elements
ENGLISH 5
1. Brake lever, engine brake 11. Height Adjuster Indicator
2. Handle 12. Spark plug
3. Throttle lever (582 only) 13. Muffler
4. Rope Eyelet 14. Oil filler pipe
5. Starter grip
6. Grascatching device
7. Ejection shield
15. Handle Screw
8. Handle Bolt 16. Height Adjuster
9. Fuel Tank
10. Air Filter
17. Primer (582SM only)
Fig. 1b
Model 582SM
