P5.
4. MOUNTING
The heater should always be angled
downwards when mounted as shown.
Always allow the heater to cool before
attempting to reposition/move. Never
attempt to move the heater while it is
switched on.
(a)
Ensure the minimum safe distance between the heater body and
infammable surfaces and objects when mounting refer to table below
and drawing (a).
MIN. DISTANCE
F ROM AWNING
MIN. DISTANCE
FROM SIDE
WALL
DIMENSIONS
W X H X D
WEIGHT
(LBS)
ENVIRONMENTAL
RATING
MINIMUM
DISTANCE
FROM
GRILL
MIN. DISTANCE
FROM FLOOR
1fT 3 1/2fT 22” x 4
½” x 6
1/4’
6.2 Ip24 6fT 7fT
AND/OR CEILING
