P6.
Step One
Step Two
4.1 MOUNTING WITH WALL BRACKET (ATTACHED TO THE HEATER)
ENSURE THAT VALANCE OF THE AWNING DOES NOT OBSTRUCT WITH
HEATER WHEN RETRACTED. REFER TO DRAWINGS BELOW.
Securely fasten the Infrared Heater RTS
(1) to the wall using the fxing holes in
the wall bracket (3). Securely fasten the
RTS heat receiver bracket (2) to the wall
bracket.
Rotate the heater to the required angled position and tighten
the fxing bolt located on the bracket at the rear of the heater.
3.
