Sonance Invisible series Installation Instructions

3
ISW
IS2
The ISW is a low frequency reinforcement to the IS line. Two voice coils drive the diaphragm
for unsurpassed invisible low end response.
The IS2 is designed for tight installations or very small spaces yet delivers sound that is only
bested by the IS4.
SPECIFICATIONS
Woofer 170 sq. in (1098 sq. cm) planar diaphragm, driven by two 2” (50mm)
voice coils
Frequency Response 35Hz – 150Hz ±3dB
Impedance 8 ohms nominal
Power Handling 100 watts RMS
Sensitivity 90dB (1W/1 meter)
Dispersion 170º hemispherical up to 10kHz
Finish Paper surface ready for texture and paint
Overload Protection Self-resetting gel switch
Cutout Dims -
Without Enclosure (WxHxD) 16-1/8” x 24-1/8” x 2” (409mm x 613mm x 51mm)
Cutout Dims -
With Enclosure (WxHxD) 16-1/8” x 24-1/8” x 3-13/16” (409mm x 613mm x 97mm)
Shipping Weight 13 lbs (5.85 kg) each
SPECIFICATIONS
Tweeter 4 sq. in (27 sq. cm) planar diaphragm, driven by a 1” (25mm) voice coil
Woofer 50 sq. in (320 sq. cm) planar diaphragm, driven by a 1” (25mm) voice coil
Frequency Response 50Hz – 20kHz ±3dB
Impedance 8 ohms nominal
Power Handling 80 watts RMS
Sensitivity 88dB (1W/1 meter)
Dispersion 170º hemispherical up to 10kHz
Finish Paper surface ready for texture and paint
Overload Protection Two independent self-resetting gel switches (low and high)
Cutout Dims -
Without Enclosure (WxHxD) 16-3/32” x 12-3/32” x 2” (409mm x 307mm x 51mm)
Cutout Dims -
With Enclosure (WxHxD) 16-3/32” x 12-3/32” x 3-13/16” (409mm x 307mm x 97mm)
Shipping Weight 12 lbs (5.5 kg) pair

Sonance Invisible series Specifications

General

Dimensions	Varies by model
Cutout Size	Varies by model
Mounting Depth	Varies by model
Type	Invisible
Power Handling	200 Watts
Impedance	8 Ohms
Installation	In-wall
Sensitivity	89dB
Finish	Paintable
Tweeter	None (uses planar diaphragm technology)
Woofer	None (uses planar diaphragm technology)
