8
11. Connect speaker wire to the appropriate terminal on
the speaker. (Speaker shown with optional enclosure.)
12. Insert speaker into opening.
13. Secure speaker with at least 4 drywall screws on each
side. Top and bottom are optional. Do not over tighten.
14. Go to Finishing Instructions starting on page 12.
NEW CONSTRUCTION
TEST THE SPEAKER FOR 60 SECONDS WITH
AN AUDIO SOURCE BEFORE COVERING WITH
DRYWALL COMPOUND!
This is the last point any wiring corrections can
be made. After test is complete finish securing with
remaining drywall screws.
