Sonic · Step up with Pep 5
Bernafon Veras IFU ITC
VR_ILU_ITC1overview_BW_HI
4
6
7
8
5
1
2
3
1 Vent
2 Canal
3 Sound outlet with wax protection
4 Microphone opening
5 Battery door
6 Push button (optional)
7 Volume control (optional)
8 Second microphone opening
Pep ITCD
1 Vent
2 Canal
3 Sound outlet with wax protection
4 Microphone opening
5 Battery door
6 Push button (optional)
7 Volume control (optional)
Bernafon Veras IFU ITC
VR_ILU_ITC2overview_BW_HI
3
4
6
5
7
1
2
Pep ITC
Pep CIC
1 Vent
2 Canal
3 Sound outlet with wax protection
4 Microphone opening
5 Battery door
6 Removal cord
Bernafon Veras IFU CIC
VR_ILU_CICoverview_BW_HI
1
5
2
3
4
6
