SonicWALL NSa Series Installation Guide

Führen Sie zum Einsetzen des neuen Lüftermoduls in die SonicWall-
Appliance die folgenden Schritte durch:
1 Bei ausgeschaltetem Gerät, legen Sie das Lüftermodul in den
leeren Steckplatz mit der gleichen Ausrichtung, die sie sich beim
Ausbau des defekten Lüfters gemerkt haben.
2 Schieben Sie das Lüftermodul fest in Position, bis es vollständig
sitzt und einrastet.
3 Bringen Sie den Haltebügel über das Lüftermodul und ziehen Sie
die Befestigungsschraube mit Daumen+Zeigefinger oder einem
Schraubenzieher fest, um die Halterung sicher zu befestigen.
4 Prüfen Sie, dass der neuen Lüfter ordnungsgemäß funktioniert.
風扇更換和安裝
本文為您提供在您的 SonicWall 網路安全設備中更換系統風扇的指
引。
從設備中卸下風扇
若要從 SonicWall 裝置取出風扇模組，請執行下列步驟：
1 利用手指或必要時使用十字螺絲起子，鬆開固定的指旋螺絲。
2 記住風扇在設備中的方向，將把柄拉到最開，直到扳直為止。
如此將會分開風扇的接觸點。
3 等待數秒鐘，等風扇停止旋轉。
4 將開風扇模組模組向外拉，將它直接從裝置完全取出。
將風扇模組裝入設備中
若要將新風扇模組模組裝入 SonicWall 裝置，請執行下列步驟：
1 在設備是關機之下，依您取出風扇模組的相同方向，將風扇模
組插入空的插槽。
2 穩穩地將模組推入直到它完全的定位，並將把柄反摺。
3 回到固定風扇模組的橫跨支架，使用螺絲起子將固定螺絲鎖
緊，以牢靠的固定支架。
4 打開設備，確認新的風扇是否工作正常。
This fan is for use only with SonicWall appliances indicated below. Use
of this fan with a SonicWall appliance that is not approved will void the
warranty for that appliance. This fan is provided as a replacement fan,
and is provided on an “as is” basis without warranty of any kind.
This fan, 01-SSC-0025 SONICWALL HIGH-END NSA NSSP SERIES FAN
FRU, is approved for use with:
SonicWall NSsp 13700 and lower-numbered NSsp models
SonicWall NSa 4700 and higher NSa x700 models
SonicWall NSa 4650 and higher NSa xx50 models
For information and related documents, see the following web site:
https://www.sonicwall.com/support
Copyright © 2021 SonicWall Inc. All rights reserved.
SonicWall is a trademark or registered trademark of SonicWall Inc. and/or its affiliates in the
U.S.A. and/or other countries. All other trademarks are property of their respective owners.
The information in this document is provided in connection with SonicWall Inc. and/or its
affiliates' products. No license, express or implied, by estoppel or otherwise, to any
intellectual property right is granted by this document. SonicWall Inc. and/or its affiliates do
not make any commitment to update the information contained in this document. For more
information, visit http://www.sonicwall.com/legal.
SonicWall NSsp/High-End NSa Series Fan Module Installation Guide
Updated - August 2021
232-004337-52 Rev A
注意 : 在更換風扇前不需要斷開電源。
警告 : 風扇的潛在危險
警告 : 除了風扇模組之外，不可插入任何裝置到設備中。
Legend
WARNING: A WARNING icon indicates a potential for property damage,
personal injury, or death.
CAUTION: A CAUTION icon indicates potential damage to hardware or loss of
data if instructions are not followed.
IMPORTANT, NOTE, TIP, MOBILE, or VIDEO: An information icon indicates
supporting information.
SonicWall NSa/NSsp
Fan Module
Installation Guide

SonicWALL NSa Series Specifications

General

Maximum Connections	1, 000, 000
VPN Throughput	Up to 1.5 Gbps
Operating System	SonicOS
Form Factor	1U Rackmount
Management	Cloud Management
Security Services	Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, Application Control
Ports	8x1GE
Power Supply	Redundant power supplies (optional)
