SonicWALL SonicPoint Getting Started Guide Page 25
Connecting the PoE Cable
If your deployment uses a SonicWALL PoE injector, read and
comply with instructions provided with the PoE first, then
complete the following steps:
1. Plug the power cord of the SonicWALL PoE injector into the
power outlet.
2. Using Ethernet cable (not included), connect the Data in
port on the SonicWALL PoE Injector to the WLAN zone
interface that you created earlier.
3. Using Ethernet cable, connect the Data and Power out
port on the SonicWALL PoE injector to the LAN port on the
back of your SonicPoint.
4. Wait for the link LED to illuminate. This indicates an active
connection. It takes approximately one minute for the
SonicWALL security appliance to auto-provision.
