5 Webpage Interface
The Title Bar
This contains the company logo and the logo for the product, showing that
you are connected to the right product type. Also, the current webpage
version and IP data is displayed here. Under the logo is the menu bar where
the page selection is made. There are three options:
1. Basic Settings – This is the default page where all the basic settings are
selected.
2. Advanced Settings – This option provides a drop down menu where all
the advanced pages are selectable by category. A guide to using the
advanced pages is provided elsewhere.
3. Update – This allows firmware updates on the Pro Audio Streamer to
be carried out.
Simply click on which page you would like to select and it will load into the
browser.
The Data Section
This section provides the main data for the selected page. Each page has a
title written in bold, blue text, which is capitalised. Next to the title, there
is a question mark. Click on the question mark to reveal a help box on the
right of the data section which will give tips on setting up the unit.
Under each title are the basic options for setup. To enter your own settings,
change the required parameter and hit the submit button at the bottom of
the page. If you change your mind and want to return all settings to as they
were before the change, refresh the page in your browser.
The Help Box
The Help Box to the right of the screen contains tips and guidance for
setting up the unit. All of the information contained in the advanced section
of the manual is contained within this box.
The Status Box
The status box is the blue box located at the bottom of the page. In here,
the unit status is presented. The values that are shown are snapshots of a
dynamic value, so remember to refresh the page to get an accurate picture
of the current scenario.
The webpage is compatible with all major browsers, including internet
exporer, safari, opera, firefox and chrome. Please note that the webpage
requires Javascript to be enabled to function properly.
Configuring The Pro Audio Streamer
The next chapter contain some application notes on setting up the webpage
for particular applications. Use the help box if you’re unsure what a
particular function should do.
