Sonoff MINI Extreme MINIR4 User Manual

English
3.Add device
Tap “+” and select “Bluetooth Pairing”, then operate following the prompt on the App.
2. Power on
After powering on, the device will enter the Bluetooth Pairing Mode defaulted during
the first use, and the Network indicator flashes in a cycle of two short and one long.
The device will exit the Bluetooth Pairing Mode if not been paired within 10mins. If
you want to enter this mode again, please long press the button for 5s until the
Network indicator flashes in a cycle of two short and one long and then release.
11

Sonoff MINI Extreme MINIR4 Specifications

General

Model	MINIR4
Category	Switch
Wireless Standard	IEEE 802.11 b/g/n 2.4GHz
Max Load Current	10A
Max Load Power	2400W
Operating Humidity	5%-95%RH, non-condensing
Casing Material	PC V0
App Compatibility	eWeLink
Certification	CE, FCC, RoHS
Input Voltage	100-240V AC 50/60Hz
Output Voltage	100-240V AC
Operating Temperature	-10°C to 40°C
