SONOFF TECHNOLOGIES CO., LTD.
English
ON OF F
ON OF F
ON OF F
ON OF F
To avoid electric shocks, please consult the dealer or a qualified professional for
help when installing and repairing! Please do not touch the switch during use.
Make sure the neutral wire and live wire connection is correct.
1. Power off
2. Wiring instruction
Operating Instruction
6
Light fixture wiring instruction:
LIn
NIn
LOut
N
E E
LIn
NIn
LOut
N
100-240V
AC
Appliance wiring instruction(Don’t
need to connect if no ground wire):
