Sonoff TX Series User Manual

Operating Instruction
1. Power off
To avoid electric shocks, please consult the dealer or a qualified professional for
help when installing and repairing!
2. Wiring instruction
1
L In Out
N In
Out Out
100-240V AC
N
L
3C
Neutral input
Live output
N In
Out Out Out
Live input
L In
Light fixture wiring instruction:
L In Out
N In
Out
2C
100-240V AC
N
L
LOut
LOut
SONOFF TECHNOLOGIES CO., LTD.
English
ON OFF
ON OFF
ON OFF
ON OFF

Sonoff TX Series Specifications

General

Voice Assistants	Amazon Alexa, Google Assistant
Connectivity	Wi-Fi
Max Current	10A
Input	100-240V AC 50/60Hz
Output	100-240V AC 50/60Hz
Operating Humidity	5%-95% RH, non-condensing
Certification	CE, FCC, RoHS
Type	Smart Switch
Control	App, Voice, Manual
Voltage Range	100-240V AC
Wireless Standard	IEEE 802.11 b/g/n
Operating Temperature	0°C to 40°C
Gang Options	1 Gang, 2 Gang, 3 Gang
Dimensions	86 x 86 x 35 mm
