BA_SPHRD_engl_080129 page 15
(...)
Application of the probes
Air sound probe
The air sound probe is used to prove ultrasound. One can connect the
probe directly to the testing device, but it is also possible to use it
separately with the extension cable.
An increase of the accuracy of the detection is reached by the plug-on
of the directional tube. For the point-exact troubleshooting additionally
the directional tip is put on the pipe.
The probe can be screwed onto the clamp holder or magnetic holder for
a signal capturing during a longer period.
directional tube
directional tip
