Getting to know your phone
Phone overview
1 Directional buttons
10
1
2
3
4
5
6
7
8
9
12
11
20
19
18
17
13
14
16
15
2 Game menu
3 Touch pad
4
Button
5
Button
6
Button
7
Button
8 Select key
9 Start key
10 Main microphone opening
11 Light sensor/ Proximity sensor
12 Ear speaker
13 Front camera
14 3.5 mm headset connector
15 Touch screen
16 Connector for charger/ USB cable
17 Back key
18 Home key
19 Menu key
20 Search key
21 Power key/Screen lock/Notification LED
22
21
23
24
25
28
29
26
27
22 Second microphone opening
23 Camera LED flash
24 Left trigger
25 Camera lens
26 Volume key
27 Right trigger
28 Strap holder
29 Speakers
