Getting to know your phone
Phone overview
21 3
10
11 9 8
5
6
7
4
1214
13
15
16
17
18
19
20
1. Notification LED/Battery status
2. Proximity sensor 1
3. Proximity sensor 2
4. Ear speaker
5. Front camera
6. Light sensor
7. Touchscreen
8. Menu key
9. Home key
10. Back key
11. Keyboard
12. Power key/Screen lock
13. Connector for charger/Micro USB cable
14. Headset connector
15. Camera LED light
16. Camera lens
17. Volume key/Zoom key
18. Camera key
19. Speaker
20. Strap hole
