Sony 6L - Bracket Installation Preparation; Prepare Necessary Items; Deciding on Installation Location

5 (GB)
GB
Preparing for installation
• Have the TV’s Reference Guide at hand before installation.
• Confirm the installing position of your TV.
• Prepare eight or more screws of 8 mm diameter (not supplied). Select screws suitable for the
material of the wall.
• Be sure that five or more persons carry or dismount the TV.
Installing the Brackets on the Wall
1 Prepare necessary items.
Wall-Mount Bracket accessories (supplied)
Paper Template Screw (+PSW M8 × 25) (4) Pulley (4)
Wall-Mount Bracket (1)
Wall-Mount Bracket (1)
2 Deciding on the installation location
Refer to the TV installation dimensions table. For details, refer to the TV’s Reference Guide.
Allow for suitable clearance between the TV and the ceiling and protruding parts of the wall as
shown below.
300
(11 /)
100
(4)
100
(4)
100
(4)
Unit: mm (inches)
