Video section flowchart
Reproduced video does not appear right
Yes
Is the FL display/LED display correct?
No
To Main flowchart
Yes
Is the drive operating properly?
No
To Drive flowchart
Yes
Check the input power
No
IC101 pin D16 & E16 : +3.3V
Yes
Is a video signal output from IC101
?
No
Check the writing from IC101
Yes
Is a signal output from each Video output
connector?
No
Check output inductors (L902)
BDP-BX18/S185/S186
To Power (System) flowchart
Pin B18 : VDACX_OUT
IC101 pin D12 : +3.3V
Check output resistors (R920)
To Next Page
