Sony BDP-S5200 Service Manual

1-1
BDP-S1200/BX120/S3200/BX320/S4200/S5200/BX520
1-1. TEST DISC
Part No. Description Layer
J-6090-199-A BLX-104 Single Layer
J-6090-200-A BLX-204 Dual Layer
J-2501-307-A CD (HLX-A1)
J-2501-305-A HLX-513 Single Layer (NTSC)
J-2501-306-A HLX-514 Dual Layer (NTSC)
J-6090-077-A HLX-506 Single Layer (PAL)
J-6090-078-A HLX-507 Dual Layer (PAL)
1-1-1. Operation and Display
Check Items
1) BLX-104
1. Select 23.976Hz/1080p
2. Play “4.Motion pictures”
3. Check whether player can play back or not
4. Check each outputs
Video:
Composite/component/HDMI
Audio:
Digital out (Coaxial/Optical)/Audio out/5.1Ch output
* When 1080/24p monitor is nothing, 1080i (59.94Hz or 50Hz) can use instead of 1080/24p.
However this is temporary correspondence.
2) BLX-204
1. Select 1080i (59.94Hz or 50Hz)
2. Play “4.Motion pictures”
3. Check whether player can play back or not
(Check the picture and sound output)
3) CD (HLX-A1)
Check whether player can play back or not
(Check the sound output)
4) HLX-513/514 (NTSC), HLX-506/507 (PAL)
1. After displayed Main Menu, select “1.Video”
2. Play “1.Color Bar 100%”
(Check the picture and sound output)
3. Return to Menu
4. Play “Demonstration 4:3” or “Demonstration 16:9”
(Check the picture and sound output)
SECTION 1
SERVICE NOTE

Sony BDP-S5200 Specifications

General

Depth	199 mm
Width	265 mm
Height	43 mm
Weight	900 g
Child lock	Yes
Device type	Blu-Ray player
Product color	Black
Audio decoders	Dolby TrueHD, DSD, DTS-HD Master Audio
DVD region code	1
Blu-ray region code	A
Disc types supported	BD, BD-RE, BD-ROM, CD, CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW
Supported video modes	1080i, 1080p, 480i, 480p, 720p
Card reader integrated	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio formats supported	AAC, AC3, FLAC, HE-AAC, M4A, MKA, MP3, WAV, WMA
Image formats supported	GIF, JPEG XR, JPG, MPO, PNG
Video formats supported	3G2, 3GP, ASF, AVI, FLV, M2TS, M4V, MKV, MOV, MP4, MPEG, MPG, MTS, WMV
Analog signal format system	NTSC, PAL
On Screen Display (OSD) languages	ENG, ESP, FRE, POR
Smart TV	No
Audio output channels	7.1 channels
