Sony BDP-S5200 Service Manual

1-2-3. BU Check Flow [zz] ~
Before BU Replacement
Optical Block Unit (BU) IOP check fl ow (zz) ~ [Before BU Replacement]
1-2.DRIVE REPAIRING
1-2-1. Preparation
• ESD Measures
It is necessary to check the working space ESD condition
before starting the Drive Part (BU) repairs
The ESD-resistance of BD Laser is weaker than DVD/CD Laser
To prevent ESD destruction, please make sure the working
space and human ESD.
•
•
1-2-2 BU (Optical Block) Repair Guide
BDP set series component structure is as same as conventional DVD Players.
However BD player requires precise read out functions and also secure contents Protection system.
Since above requirement, it is necessary to set/adjust BU data to EEPROM.
The following cases need Adjustments;
(1)Replace BU (MB is original)
(2)Replace MB (BU is original)
(3)Replace both BU and MB
•JIG Requirement
Digital camera (recommend with macro mode)
Barcode decoder (BDPRdec_ver3.0) installed in JIG PC’s
USB memory
ESD work bench
•Procedure (all cases) Refer the diagram
Remarks:
The servo adjustment procedure will be carried out during OP data Writing.
There is no manual adjustment procedure. LD ON TIME history doesn’t carry over.
Do not touch any optical block parts, Turn Table and during replacing. BD Laser diode
is very sensitive!
1-2
BDP-S1200/BX120/S3200/BX320/S4200/S5200/BX520
Enter Service Mode
Press <OPEN/CLOSE>, <PLAY>,<STOP>
and plug in AC Power
Inside *Service Mode Menu
Select [8] Drive
Inside *Drive
Select [7] OP Check Menu
Inside *OP Check Menu
Select [3] dIOP then press ‘ENTER’
Specifi cation dIOP
BD: ± 6mA
DVD, CD: ± 9mA
AC Power OFF
IOP out of specifi cation need BU
replacement
Optical Block Unit (BU) replace
(Flowchart yy)

Sony BDP-S5200 Specifications

General

Depth	199 mm
Width	265 mm
Height	43 mm
Weight	900 g
Child lock	Yes
Device type	Blu-Ray player
Product color	Black
Audio decoders	Dolby TrueHD, DSD, DTS-HD Master Audio
DVD region code	1
Blu-ray region code	A
Disc types supported	BD, BD-RE, BD-ROM, CD, CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW
Supported video modes	1080i, 1080p, 480i, 480p, 720p
Card reader integrated	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio formats supported	AAC, AC3, FLAC, HE-AAC, M4A, MKA, MP3, WAV, WMA
Image formats supported	GIF, JPEG XR, JPG, MPO, PNG
Video formats supported	3G2, 3GP, ASF, AVI, FLV, M2TS, M4V, MKV, MOV, MP4, MPEG, MPG, MTS, WMV
Analog signal format system	NTSC, PAL
On Screen Display (OSD) languages	ENG, ESP, FRE, POR
Smart TV	No
Audio output channels	7.1 channels
