Sony BDV-IT1000 - Page 148

148
GB
General
Power requirements 220 - 240 V AC, 50/60 Hz
Power consumption On: 140 W
(BDV-IT1000) Standby: 0.3 W (at the
Power Saving mode)
Power consumption On: 100 W
(BDV-IS1000) Standby: 0.3 W (at the
Power Saving mode)
Output voltage/current
(DIGITAL MEDIA PORT)
DC 5 V/700 mA
LAN (100) 100BASE-TX Terminal
EXTERNAL External memory slot (For
connecting the external
memory)
DC output: 5 V 500 mA
Max
Dimensions (approx.) 430 mm × 125 mm × 355
mm (w/h/d) incl.
projecting parts
430 mm × 125 mm × 385
mm (w/h/d) with the
wireless transceiver
inserted
Mass (approx.) 10 kg
Surround amplifier (TA-SA100WR)
Amplifier Section (BDV-IT1000)
RMS output power (reference)
100 W + 100 W
(at 3.5 ohms, 1 kHz, 10 %
THD)
Amplifier Section (BDV-IS1000)
RMS output power (reference)
50 W + 50 W
(at 10 ohms, 1 kHz, 10 %
THD)
Rated impedance 3 - 16 Ω
General
Power requirements 220 - 240 V AC, 50/60 Hz
Power consumption On: 50 W
Dimensions (approx.) 85 mm × 100 mm × 330
mm (w/h/d) (incl. EZW-
RT10)
85 mm × 100 mm × 345
mm (w/h/d) incl. speaker
cord cover and speaker
cord holder
Mass (approx.) 1.7 kg incl. speaker cord
cover and speaker cord
holder
Wireless transceiver (EZW-RT10)
Communication system S-AIR Specification
version 1.0
Output 12.0 mW
Frequency band 2.4000 GHz - 2.4835 GHz
Modulation method DSSS
Power requirements DC 3.3 V, 350 mA
Dimensions (approx.) 50 mm × 13 mm × 60 mm
(w/h/d)
Mass (approx.) 24 g
Design and specifications are subject to change
without notice.
• Standby power consumption 0.3 W.
• Halogenated flame retardants are not
used in the printed wiring boards.
• Over 85% power efficiency of
amplifier block is achieved with the
full digital amplifier, S-Master.
