Getting Started
5 Attach the grille to the speaker.
Be careful with the orientation of the grille. The "SONY" logo should be at the left side of the
grille.
Note
• When assembling, take care not to touch the speaker unit.
• Be sure to use the speakers with their grilles attached.
• Do not push on the attached grille. It may cause damage to the speaker unit.
6 Attach the foot pads to the bottom of the speaker.
Attach the foot pads (thick) to the front of the speaker and the foot pads (thin) to the rear so that
the speaker tilts up when installed on a TV stand, etc.
Grille
“SONY” mark
Foot pads (thick)
Foot pads (thin)
Bottom of the center speaker
Side view
Foot pads (thin)
Foot pads (thick)
To Next Page
