Index to Parts and Controls
For more information, refer to the pages indicated in parentheses.
A Disc slot (page 25)
B Front panel display
C (remote sensor)
D USB 2 port (page 26)
Open the cover using a fingernail in the slot.
E Soft-touch buttons/indicators
N (play)
x (stop)
./> (previous/next)
Z (eject)
FUNCTION (page 23)
Selects the playback source.
VOL +/–
F Power indicator
Lights up while the system is turned on.
G "/1 (on/standby)
Turns on the unit, or sets it to standby mode.
About soft-touch buttons/
indicators
These buttons function when the soft-touch
button indicators are lit.
You can turn on/off the indicators by setting
[Illumination/Display] (page 46). When you set
[Illumination/Display] to [Auto], the indicators
turn off. In this case, touch any soft-touch
button. When the indicators light up, touch the
desired button.
• These buttons work when you touch them lightly. Do
not press on them with excessive force.
Front panel
FUNCTION
VOL VOL
USB 2
Slot
