− 13 (EN) −
EN
Attaching the Wall-Mount
Bracket to the Solid Concrete or
Concrete Block
WM1
Installing the Wall-Mount
Bracket to the Wall
1 Decide on the installation
location.
Make sure that the wall has enough space
for the TV and is capable of supporting a
weight of at least six times that of the TV.
• Refer “Measurement for Wall-Mount
Bracket installation on the wall” on page
22.
• Refer to your TV’s Reference Guide for the
TV’s weight.
Note
When your TV is installed on the wall, the upper
side of the TV slightly leans forward.
We recommend you to check the position of TV in
the viewing environment.
6
WARNING
Two or more persons (three or more persons for
189.3 cm (75 inches) and above TV) are needed to
transport a large TV set.
Confirming the Completion of
the Installation
Check the following points.
The cord and the cable are not twisted or
pinched.
WARNING
Improper placement of the AC power cord, etc. may
cause fire or electric shock through a short circuit. Be
sure to confirm the completion of the installation for
safety.
Other Information
When removing the TV, reverse the previous
installation procedure.
WARNING
Two or more persons (three or more persons for
189.3 cm (75 inches) and above TV) are needed to
transport a large TV set.
To Next Page
