− 14 (EN) −
5 Install
WM1
on the wall.
WS2
WW1
WM1
Note

Use a level to check whether
WM1
is level.
Precaution

Do not over-tighten the lag bolts
WS2
. Improper
tightening could reduce the holding power of the
lag bolts
WS2
.
6 Pull out the arm of the bracket to
the end.
Preparing for the Installation
of the TV
Note

Be sure to store the removed screws and unused parts
in a safe place, keeping them away from children.
2 Align
WM1
to the wall and make
four marks.
× 4
WM1
Note

Use a level to check whether
WM1
is level.
3 Drill pilot holes on the marks.
Make sure the location on the wall to drill
the holes are strong enough to support a
weight of at least six times that of the TV.
× 4
75mm
(3inch)
10mm
(13/32inch)
Note

Pilot holes must be drilled to a depth of 75mm
(3inch), using a 10mm (13/32inch) diameter drill
bit.
4
WA1

Sony BRAVIA XR-55A80L Specifications

General

Screen Size	55 inches
Display Type	OLED
Refresh Rate	120 Hz
Processor	Cognitive Processor XR
Smart TV Platform	Google TV
HDMI Ports	4
Voice Assistant	Google Assistant, Amazon Alexa
USB Ports	2
Resolution	3840 x 2160
HDR	Dolby Vision, HDR10, HLG
Audio	Acoustic Surface Audio+
Wi-Fi	Wi-Fi 802.11a/b/g/n/ac
Bluetooth	Bluetooth 4.2
Dimensions (W x H x D)	1227 x 711 x 53 mm (without stand)
