• BKM-30E14
Overview
Components
The BKM-30El4 is a rack mount kit for mounting a Sony BVM series 14-
rnch stand-alone monitor in an EIA standard 19-inch rack.
The BKM-30E 14
consisis of the following components. Check to make
sure that you have all the components before beginning assembly.
The circled letters A to I in the table below correspond 10 those in the
illustrations on the subsequent pages.
Part
@ IRailA
~
.
.
@ IRailB
~
.
.
© I Front bracket
~
@ I Rear bracket
~
~
© J Plalenut
Judge, from the position of
Long
1
~
Top
the screw holes (as shown
1n the figure). which side 1s
I !
the top.
Short
I
I
Bollom
®
Screw(:t)M4x6
~
@
Screw @PSW4x20
~
®
Screw @M4x10
~
<D
Flange nut M4
®
Qty !Part no.
2 I 2-370-211-02
(Shipped wilh rail A
inserted
1n rail 6.)
2 14-051-611·01
2
I 4·051-612-01
4 I 4·051-259-01
I 4 I 7-682-160-01
I 8 I 7-682-966-01
I 4 I 7-682-162-01
I 4 I 4-304-749-01
Assembly
1 Remove the (pur feet from the
bottom of the monitor.
2 Pull out rail A from rail 8.
mm
Take care not to get your
fingers
L·aught betwe~n 1he
rails .
3 Anach rail A to th!! monitor.
4 Attach the front bracket and
rear bracket to rail H.
..
;,--t--r- Feet
..
..
Plate spnng
@
©
fnmti1111rd>
------------------------------------------------------·------~---·-···--·-----'"··
To Next Page
