Sl-l: DOLBY NR System LOCK SW
ON: Dolby NR System ON/OFF is
controlled by S1-2 and S1-3 in both
record and playdDack modes.
S1-2: Dolby NR System ON/OFF for CH-1
S1-3: Dolby NR System ON/OFF for CH-2
OFF: Dolby NR System ON/OFF is
controlled by Dolby NR Switeh behind
the control panel in record mode.
Dolby NR System ON/OFF is
controlied by automatic detection at
playback mode.
NOTE:Dolby NR Switch behind the control
panel, automatic detection S1-4 and S2
don't function.
This switch is set to the OFF
position at exfactory.
$1-2: CH-1 DOLBY NR ON/OFF Switch
Refer to (1)
This switch is set to the OFF position at
exfactory.
Sl-3: CH-2 DOLBY NR ON/OFF Switch
Refer to (1)
This switch is set to the OFF position at
exfactory.
Si~4: DOLBY NR PLAYBACK Select Switch
This switeh functions when Si-l is OFF.
In record modes
When using the KSP tepe, Dolby NR System
is activated by Dolby NR Switch behind the
control panel regardiess of this switch
setting.
When using KCA and KCS tapes, Dolby NR
System is not activated.
In playback mode:
ON: Dolby NR ON/OFF is controlled by
Dolby NR Switeh behind the control
panel.
OFF: Regardless of Dolby NR switch
setting behind the control panel Dolby
NR System is activated automatically.
When video is SP mode (SP lamp is
ON.), regardiess of ON/OFF setting of
Dolby NR Switch Dolby NR System is
activated automatically.
When video is NON-SP mode (SP lamp
is OFF.), Dolby NR System is not
activated.
This switch is set to the OFF position at
exfactory.
DOLBY NR Switch positions
DOLBY NR DOLBY NR
ON/OFF only ON/cer for
for SP vane all tapes
Both channeis | Both ckannets Chel CH?
ON/OFF enh | ON/GFF enh | DOLBY NR | DOLBY NR
Ov REC wasede suntch jineede swnch | ON/OFF ON/OFF
Operenca nae on the fron on the front wah $1.2 wuh Si-3
| pens
AUTO
t 1! !
Dunes PO onworrF
Seuch Sl-t OFF OFF ON ON
woung $i-2 x x ON/OFF x
oa
AU $t-3 x x x Ow/OFrF
beard Si-4 OFF ON x
it alweys be Insede rentch
comes on the from
DOLSY NR peaci dors not _
Remerts OFF (ler the fenchon.
coavennesas!
tapes.
Note: X marks show that the switch does not function.
—_>
1-7
