16(E)
Connections
Power Supply
When a Camera Control Unit is connected
When the POWER switch is set to u CCU,
power is supplied from the CCU.
To supply a power from the DC connector
Set the POWER swicth to 1 EXT.
When a VTR is connected
When the POWER switch is set to 1 EXT,
Power is supplied from the VTR.
When the CA-570/570P is attached to the VTR and power is supplied from
the DC IN connector, external power supply is automatically selected.
Note
Due to the large power consumption of the BVF-55/55CE viewfinder, the
viewfinder cannot be used when power is being supplied from a portable
VTR.
