Sony CA-TX7/TX7P - Specifications

15
When power is supplied via the DC IN connector
Operating temperature
–10ºC to +45ºC (14°F to 113°F)
Operating humidity
20% to 90%
Storage temperature
–20ºC to +60ºC (–4ºF to 140ºF)
Mass Approx. 2.7 kg (5 lb 15 oz)
External dimensions
226 × 221 × 131 mm (9 × 8
3
/4 × 5
1
/4 inches) (w/h/d)
General
Power requirements
When supplied via the CCU
connector: 120 V AC
When supplied via the DC IN
connector: 12 V DC (10.5 to 17
V DC)
Power consumption
Varies according to connected
equipment as shown in the
following tables
1)
:
When power is supplied via the CCU connector
Specifications
Power consumption
CA-TX7/TX7P CA-TX7/TX7P
and connected
equipment
CA-TX7/TX7P 10.5 W
CA-TX7/TX7P+DXC-
D30/D30P
11 W 23.7 W
CA-TX7/TX7P+DXC-
D30/D30P+DXF-701/
701CE
11.2 W 26 W
CA-TX7/TX7P+DXC-
D30/D30P+DXF-51/
51CE
12.3 W 35 W
CA-TX7/TX7P
outputting 12 W from
the DC OUT
connector+DXC-D30/
D30P+DXF-51/51CE
13.3 W
48 W
Power consumption
CA-TX7/TX7P CA-TX7/TX7P
and connected
equipment
CA-TX7/TX7P 7.5 W
CA-TX7/TX7P+DXC-
D30/D30P
7.5 W 20.2 W
CA-TX7/TX7P+DXC-
D30/D30P+DXF-701/
701CE
7.5 W 22.3 W
CA-TX7/TX7P+DXC-
D30/D30P+DXF-51/
51CE
7.5 W 30.2 W
CA-TX7/TX7P
outputting 12 W from
the DC OUT
connector+DXC-D30/
D30P+DXF-51/51CE
7.5 W 42.2 W
1) The power consumption indicated on the name plate of
the unit is total consumption of the CA-TX7/TX7P
outputting 12 W from the DC OUT connector, DXC-
D30/D30P, and DXF-51/51CE.
..........................................................................................................................................................................................................
