Identifying the parts and controls
Attaching the lens cap
Attach the lens cap to the grip strap as illustrated.
qd
qj
qg
qh
wa
w;
ql
qk
qf
qd Video control buttons (p. 29, 31)
x STOP (stop)
m REW (rewind)
N PLAY (playback)
M FF (fastforward)
X PAUSE (pause)
qf SUPER LASER LINK button
(CCD-TRV98 only) (p. 33)
qg Microphone
qh Remote sensor (CCD-TRV49/TRV78/
TRV98 only) (p. 78)
qj Infrared rays emitter (p. 26, 33)
qk NIGHTSHOT switch (p. 26)
ql Camera recording lamp (p. 20)
w; Display window (p. 79)
wa Tripod receptacle (base)
Make sure that the length of the tripod
screw is less than 6.5 mm (9/32 inch).
Otherwise, you cannot attach the tripod
securely and the screw may damage
your camcorder.
