Sony CDP-CX455 - Page 61

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
61
CDP-CX455
DISP
C791 1-162-286-31 CERAMIC 220PF 10% 50V
C792 1-162-294-31 CERAMIC 0.001uF 10% 50V
C793 1-164-159-11 CERAMIC 0.1uF 20.00% 50V
< CONNECTOR >
CNP502 1-784-778-11 CONNECTOR, FFC 17P
< DIODE >
D701 8-719-046-39 DIODE SEL5821A-TP15 (TOP ARTIST 1)
D702 8-719-046-39 DIODE SEL5821A-TP15 (TOP ARTIST 2)
D703 8-719-046-39 DIODE SEL5821A-TP15 (TOP ARTIST 3)
D704 8-719-046-39 DIODE SEL5821A-TP15 (TOP ARTIST 4)
D705 8-719-046-39 DIODE SEL5821A-TP15 (ARTIST MODE)
D706 8-719-046-39 DIODE SEL5821A-TP15 (TOP ARTIST 5)
D707 8-719-046-39 DIODE SEL5821A-TP15 (TOP ARTIST 6)
D708 8-719-046-39 DIODE SEL5821A-TP15 (TOP ARTIST 7)
D709 8-719-046-39 DIODE SEL5821A-TP15 (TOP ARTIST 8)
D710 8-719-046-44 DIODE SEL5221S-TP15 (STANDBY)
< FLUORESCENT INDICATOR TUBE >
FL701 1-518-802-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC701 6-702-066-01 IC PT6302-R-001
IC702 8-759-183-47 IC M66310FP
IC703 8-759-827-70 IC NJL64H400A-1
< TRANSISTOR >
Q701 8-729-116-02 TRANSISTOR BA1A4M-TP
< RESISTOR >
R742 1-249-417-11 CARBON 1K 5% 1/4W F
R743 1-249-421-11 CARBON 2.2K 5% 1/4W F
R744 1-249-421-11 CARBON 2.2K 5% 1/4W F
R745 1-249-425-11 CARBON 4.7K 5% 1/4W F
R752 1-249-417-11 CARBON 1K 5% 1/4W F
R753 1-249-421-11 CARBON 2.2K 5% 1/4W F
R754 1-249-421-11 CARBON 2.2K 5% 1/4W F
R755 1-249-425-11 CARBON 4.7K 5% 1/4W F
R762 1-249-417-11 CARBON 1K 5% 1/4W F
R763 1-249-421-11 CARBON 2.2K 5% 1/4W F
R764 1-249-421-11 CARBON 2.2K 5% 1/4W F
R765 1-249-425-11 CARBON 4.7K 5% 1/4W F
R766 1-249-429-11 CARBON 10K 5% 1/4W
R767 1-249-433-11 CARBON 22K 5% 1/4W
R781 1-247-807-31 CARBON 100 5% 1/4W
R782 1-247-807-31 CARBON 100 5% 1/4W
R783 1-247-807-31 CARBON 100 5% 1/4W
R784 1-247-807-31 CARBON 100 5% 1/4W
R785 1-247-807-31 CARBON 100 5% 1/4W
R786 1-247-843-11 CARBON 3.3K 5% 1/4W
R787 1-249-441-11 CARBON 100K 5% 1/4W
R788 1-247-807-31 CARBON 100 5% 1/4W
R789 1-247-807-31 CARBON 100 5% 1/4W
R790 1-249-409-11 CARBON 220 5% 1/4W F
R791 1-249-409-11 CARBON 220 5% 1/4W F
R792 1-249-409-11 CARBON 220 5% 1/4W F
R793 1-249-413-11 CARBON 470 5% 1/4W F
< SWITCH >
S741 1-771-349-21 SWITCH, KEYBOARD (TOP ARTIST 1)
S742 1-771-349-21 SWITCH, KEYBOARD (TOP ARTIST 2)
S743 1-771-349-21 SWITCH, KEYBOARD (TOP ARTIST 3)
S744 1-771-349-21 SWITCH, KEYBOARD (TOP ARTIST 4)
S745 1-771-349-21 SWITCH, KEYBOARD (ARTIST MODE)
S751 1-771-349-21 SWITCH, KEYBOARD (TOP ARTIST 5)
S752 1-771-349-21 SWITCH, KEYBOARD (TOP ARTIST 6)
S753 1-771-349-21 SWITCH, KEYBOARD (TOP ARTIST 7)
S754 1-771-349-21 SWITCH, KEYBOARD (TOP ARTIST 8)
S755 1-771-349-21 SWITCH, KEYBOARD (TIME)
S761 1-771-349-21 SWITCH, KEYBOARD (DISPLAY)
S762 1-771-349-21 SWITCH, KEYBOARD (REPEAT)
S763 1-771-349-21 SWITCH, KEYBOARD (PROGRAM)
S764 1-771-349-21 SWITCH, KEYBOARD (SHUFFLE)
S765 1-771-349-21 SWITCH, KEYBOARD (CONTINUE)
S766 1-771-349-21 SWITCH, KEYBOARD (?/1)
S768 1-570-157-51 SWITCH, SLIDE (TIMER)
**************************************************************
1-683-728-11 DOOR SW BOARD
***************
< RESISTOR >
R612 1-249-417-11 CARBON 1K 5% 1/4W F
R613 1-249-421-11 CARBON 2.2K 5% 1/4W F
R614 1-249-421-11 CARBON 2.2K 5% 1/4W F
< SWITCH >
S611 1-786-154-11 SWITCH, ROTARY (DOOR)
S612 1-786-154-11 SWITCH, ROTARY (POP UP)
**************************************************************
A-4727-722-A JOG BOARD, COMPLETE (AEP, UK)
A-4727-721-A JOG BOARD, COMPLETE (US, CND)
****************************
* 4-929-709-31 GUIDE (FL TUBE)
< CAPACITOR >
C701 1-161-494-00 CERAMIC 0.022uF 25V
C711 1-161-494-00 CERAMIC 0.022uF 25V
C721 1-161-494-00 CERAMIC 0.022uF 25V
C731 1-161-494-00 CERAMIC 0.022uF 25V
C741 1-161-494-00 CERAMIC 0.022uF 25V
C751 1-161-494-00 CERAMIC 0.022uF 25V
C773 1-164-159-11 CERAMIC 0.1uF 20.00% 50V
C774 1-124-584-00 ELECT 100uF 20% 10V
C775 1-162-207-31 CERAMIC 22PF 5% 50V
C776 1-164-159-11 CERAMIC 0.1uF 20.00% 50V
C777 1-162-282-31 CERAMIC 100PF 10% 50V
C778 1-164-159-11 CERAMIC 0.1uF 20.00% 50V
C779 1-164-159-11 CERAMIC 0.1uF 20.00% 50V
(AEP, UK)
< DIODE >
D711 8-719-046-41 DIODE SEL5521C-TP15 (G)
D712 8-719-046-39 DIODE SEL5821A-TP15 (X)
D715 8-719-046-41 DIODE SEL5521C-TP15 (HISTORY)
JOGDOOR SW
