Other Functions
Establishing a LINC
Before an audio signal can be transmitted between
i.LINK components, a “LINC” must first be established
between the receiving component (of the audio signal)
and the sending component. Establishing a “LINC”
means establishing a logical path for the transmission
of digital audio signals between the two components.
Each logical path has an ID number. Since the
component that sends an audio signal must output the
signal to a path, and the component that receives the
signal must input it from the same path, the path must
be mutually known by both components. During the
establishment of a LINC, the following communication
occurs between the two i.LINK components.
Example
A component establishing a LINC with a CD player in
order to receive an audio signal from the CD player
1 The component that will receive an audio signal
from the CD player sends a request and path
information to the CD player to establish a
transmission path for the audio signal.
1
,
2
<
2 The CD player responds to the component,
agreeing to the establishment of a LINC.
The digital audio signal transmission becomes possible
only after the communication described above has
occurred and a LINC has been established.
The component
that receives
the audio signal
CD player
(sending
component)
0
GB
Additional Information
Specifications
Compact disc player
Laser Semiconductor laser (λ = 800 nm)
Emission duration: continuous
Inputs/Outputs (i.LINK S200)
i.LINK connector 4 pins - 4 pins (S200)
General
Power requirements 230 V AC, 50/60 Hz
Power consumption 22 W
Dimensions (approx.) (w/h/d)
430 × 70 × 315 mm
incl. projecting parts
Mass (approx.) 4.6 kg
Supplied accessories
i.LINK connecting calbe (4 pins - 4 pins) (1)
Remote commander (remote) (1)
Design and specifications are subject to change without
notice.
Display Messages
The following table explains the various messages that
appear in the display.
Message Error code(s) Cause and/or remedy
CANNOT
LINC
C78:11/C78:12 The player cannot establish
a LINC with a component
because of an existing LINC
between the player and
another component. Cancel
the LINC between the
player and the other
component.
BUS FULL C78:15 The signal bus within the
i.LINK configuration is full
and no more signals can be
output from the player.
Cancel the LINC between
the component and the
player.
LOOP
CONNECT
C78:03 The i.LINK connection is
looped. Check the
connection (see page 17).
NEW
CONNECT
— An i.LINK component has
been connected to or
disconnected from the
i.LINK configuration. Wait
several seconds for the
indication to turn off.
