Sony CDP-LSA1 Service Manual

9
SECTION 3
DISASSEMBLY
3-1. CASE (TOP)
Note : Follow the disassembly procedure in the numerical order given.
2
3 case (top)
1 two screws (case)
1 two screws (case)
Set Case (Top) CD Mechanism Deck
Base (Front) Assy, Panel
Tray, Gear And Cam Base Unit-1
Optical pick-up Section (CD)
Base Unit-2 (BU-21BD53A)
(Page 13)
Sub Main Board And Main Board
Trans Board
BD Board
(Page 10)
(Page 10)
(Page 12) (Page 12)
(Page 11)
(Page 11)
(Page 14)
(Page 13)
