Ref. No. Part No.
Description Remark
< SWITCH >
$201 A\ 1-571-722-11 SWITCH, VOLTAGE SELECTION
(E, Saudi Arabia)
< CRYSTAL >
X351 1-579-161-11 VIBRATOR, CRYSTAL (45MHz)
prietitictiiitisitiiiitioiiioctitie iii ss sits tse sti sts tes ooo
637-818-11 POWER SW BOARD (MADE 1N JAPAN)
6
37-818-21 POWER SW BOARD (MADE IN FRANCE)
HREEE EEE EEE ERE EEE EEE EEE EER EEE
* I-
* I-
< CONNECTOR >
CH491 -& 1-568-953-11 PIN, CONNECTOR 4P
< SWITCH >
$491 1-554-118-00 SWITCH, PUSH (1 KEY) (POWER)
pereetttiitisiitti isis i sitet itis eet e sett et thst eho SL
# 1-637-820-11 VOL BOARD (MADE IN JAPAN EXCEPT M12)
# 1-637-820-21 VOL BOARD (MADE IN FRANCE EXCEPT M12)
prretisierictstopeis sss tt ists ts oes
< CAPACITOR >
C510 1-124-584-00 ELECT 100uF 20% 10V
C514 1-163-133-00 CERAMIC CHIP 470PF 5% = 50V
C512 1-163-038-00 CERAMIC CHIP 0. luF 25V
C520 1-124-584-00 ELECT 100uF 20% = 10V
C521 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
< CONNECTOR >
CN501 ¥ 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
< IC >
10501 8-759-981-86 IC RC4556MA
< JACK >
3501 1-568-519-41 JACK, LARGE TYPE (HEADPHONES)
< RESISTOR >
R510 1-216-049-00 METAL CHIP IK 5% 1/10W
R511 1-216-065-00 METAL CHIP 4. 7K 5% 1/10W
R512 1-216-067-00 METAL CHIP 5. 6K 5% 1/10
R513 1-216-025-00 METAL CHIP 100 5% 1/10
R520 1-216-049-00 METAL CHIP 1k 5% 1/10W
| CDP-M11/M12/M21/M41
Ref. No. Part No.
Description Remark
R521 1-216-065-00 METAL CHIP 4. 1K 5% = 1/10W
R522 1-216-067-00 METAL CHIP 5. 6K 5% = 1/10W
R523 1-216-025-00 METAL CHIP 100 5% 1/10W
< VARIABLE RESISTOR >
RV501 1-241-386-11 RES, VAR, CARBON 20X/20K (PHONE LEVEL)
HHRREEEREEREEEEEEE ERE EEREE EEE EE EREREEEEE AEE REE EREEREES EE
MISCELLANEOUS
HEBERT REESE EE
1 A 1-574-127-31 CORD, POWER (MADE IN FRANCE
M11/M12/M2 1: AEP)
1 A 1-574-358-31 CORD, POWER (WITH CONNECTOR)
(M11/M21:Austratian)
11 A 1-574-390-31 CORD, POWER (M12/M41:UK)
11 A 1-575-651-21 CORD, POWER (MADE IN -JAPAN
M11/M12/M21:AEP/M11:Saudi Arabia)
11 A 1-575-653-21 CORD, POWER (M11/M21:£)
12 A\ 1-569-007-11 ADAPTOR, CONVERSION 2P (M11/M21:)
12 A\ 1-569-008-11 ADAPTOR, CONVERSION 2P(M11:Saudi Arabia)
19 1-575-160-11 WIRE, FLAT TYPE (22 CORE)
25 = * 1-637-818-11 POWER SW BOARD (MADE IN JAPAN)
25 =: 1-637-818-21 POWER SW BOARD (MADE IN FRANCE)
26 =: 1-637-820-11 VOL BOARD (MADE 1N FRANCE EXCEPT M12)
26 # 1-637-820-21 VOL BOARD (MADE IN LAPAN EXCEPT M12)
311 # 1-452-538-11 MAGNET
354 1-575-001-11 WIRE, FLAT TYPE (12 CORE)
357 A\ 8-848-144-11 DEVICE, OPTICAL KSS-240A
CN401 1-535-883-11 JUMPER, FILM (WITH TERMINAL)
FLD401 = 1-519-611-11 INDICATOR TUBE, FLUORESCENT
T901A 1-449-922-11 TRANSFORMER, POWER (MADE IN JAPAN
MI1/M21:AEP, Austral ian/M12:AEP)
T1901 A\ 1-449-923-11 TRANSFORMER, POWER (MADE IN JAPAN
MI1:E, Saudi Arabia/M21:£)
1901 A\ 1-449-925-11 TRANSFORMER, POWER (MADE IN FRANCE
AEP, UK)
HERE EERE EEE EESEREEEE EE EEE EREAEEE EERE EERE EERE EERE EEA ARS
The components identified by mark A\ or
dotted line with mark A\ are critical for
safety.
Replace only with part number specified.
When indicating parts by reference
number, please include the board name.
