Sony CDX-5100 - Remote Commander Controls

12
EN
Actual total number: Sony CDX-5100 (E) 3-810-776-21(1)
Optional the Wireless
Remote Commander
(RM-X40)
Buttons with the same function as
those as those on the master unit
1 OFF button
4 SEEK/AMS button
5 PRESET/DISC button
You cannot do the manual search and manual tuning
with the remote commander.
6 MUTE button
7
–
+
button
8 DSPL button
9 SEL button
When the POWER SELECT switch is set to the B position, the unit cannot be operated with the
wireless remote commander unless the CD, FM or AM button on the unit is pressed or a CD is
inserted to activate the unit first.
OFF
MODE SOURCE
SEEK
AM 8
PRESET
DISC
–
=
+
+
+
FF
–
REW
SEL
– +
MUTE DSPL
Location of Controls
Different function buttons
2 MODE button
During radio reception:
Changes preset groups within band
received:
z FM 1 z FM2 z FM3
3 SOURCE button
Press to select program sources.
Each time the button is pressed, the
program source mode changes as follows:
z FM z AM z CD
