Sony CDX-C480 - Chassis (T) Sub Assy; Lever Assy

– 18 –
2-7. CHASSIS (T) SUB ASSY
2-8. LEVER ASSY
4 chassis (T) sub assy
2 P 2x3
3 P 2x3
1 Unsolder the
lead wires.
red
white
black
4 claws
2 DISC IN SW board
7 lever (L) assy
3 tension spring (LR)
6 lever (R) assy
5 guide (disc)
1 PS 2x4
