– 58 –
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark ! or dotted line with mark.
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
DISPLAYDISC IN SW
* 1-659-836-11 DISC IN SW BOARD
****************
< SWITCH >
SW1 1-572-288-11 SWITCH, PUSH (DISC IN)
SW2 1-572-288-11 SWITCH, PUSH (SELF)
*************************************************************
DISPLAY BOARD
**************
* X-3374-890-1 HOLDER (LCD) ASSY
* 3-019-530-01 PLATE (LCD), GROUND
* 3-019-531-01 SHEET (LCD), COLOR
3-021-407-01 SHEET (D), LCD
< CAPACITOR >
C802 1-164-222-11 CERAMIC CHIP 0.22uF 25V
C803 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C804 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C805 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
< CONNECTOR >
CNP801 1-764-423-11 PIN, CONNECTOR 12P
< DIODE >
D801 8-719-422-43 DIODE MA8051-H
D802 8-719-420-90 DIODE MA8051-M
D803 8-719-914-43 DIODE DAN202K
D806 8-719-977-12 DIODE DTZ6.8B
D807 8-719-977-12 DIODE DTZ6.8B
D808 8-719-977-12 DIODE DTZ6.8B
D809 8-719-977-12 DIODE DTZ6.8B
D810 8-719-977-12 DIODE DTZ6.8B
D811 8-719-977-12 DIODE DTZ6.8B
< IC >
IC801 8-759-365-90 IC LC75824W
IC802 8-749-012-76 IC PIC-12041T
< JUMPER RESISTOR >
JR853 1-216-295-00 SHORT 0
JR854 1-216-295-00 SHORT 0
JR855 1-216-295-00 SHORT 0
JR856 1-216-295-00 SHORT 0
JR858 1-216-295-00 SHORT 0
JR859 1-216-295-00 SHORT 0
< LIQUID CRYSTAL DISPLAY >
LCD801 1-803-028-31 DISPLAY PANEL, LIQUID CRYSTAL
< DIODE >
LED801 8-719-987-45 LED CL-155Y/PG-CD
LED802 8-719-987-45 LED CL-155Y/PG-CD
LED803 8-719-987-45 LED CL-155Y/PG-CD
LED804 8-719-987-45 LED CL-155Y/PG-CD
LED805 8-719-987-45 LED CL-155Y/PG-CD
< SWITCH >
LSW801 1-762-143-12 SWITCH, KEYBOARD (WITH LED) (6)
LSW803 1-762-143-12 SWITCH, KEYBOARD (WITH LED) (SOUND)
LSW804 1-762-143-12 SWITCH, KEYBOARD (WITH LED) (5)
LSW805 1-762-143-12 SWITCH, KEYBOARD (WITH LED) (6)
LSW806 1-762-143-12 SWITCH, KEYBOARD (WITH LED) (7)
LSW807 1-762-143-12 SWITCH, KEYBOARD (WITH LED) (8)
LSW808 1-762-143-12 SWITCH, KEYBOARD (WITH LED) (9)
LSW809 1-762-143-12 SWITCH, KEYBOARD (WITH LED) (10)
LSW810 1-762-143-12 SWITCH, KEYBOARD (WITH LED) (1)
LSW811 1-762-143-12 SWITCH, KEYBOARD (WITH LED) (2)
LSW812 1-762-143-12 SWITCH, KEYBOARD (WITH LED) (3)
LSW813 1-762-143-12 SWITCH, KEYBOARD (WITH LED) (4)
LSW814 1-762-143-12 SWITCH, KEYBOARD (WITH LED) (DSPL)
LSW815 1-762-143-12 SWITCH, KEYBOARD (WITH LED) (LIST)
LSW816 1-762-143-12 SWITCH, KEYBOARD (WITH LED) (OFF)
LSW817 1-762-143-12 SWITCH, KEYBOARD (WITH LED) (SOURCE)
LSW818 1-762-143-12 SWITCH, KEYBOARD (WITH LED) (SHIFT)
LSW819 1-762-143-12 SWITCH, KEYBOARD (WITH LED) (MODE)
< PILOT LAMP >
PL801 1-517-665-11 LAMP, PILOT
PL802 1-517-665-11 LAMP, PILOT
< TRANSISTOR >
Q802 8-729-903-46 TRANSISTOR 2SB1132-P
Q803 8-729-904-66 TRANSISTOR DTD113EK
Q804 8-729-904-78 TRANSISTOR DTD113ZK
Q805 8-729-620-06 TRANSISTOR 2SC3052-EF
< RESISTOR >
R801 1-216-647-11 METAL CHIP 680 0.5% 1/10W
