– 59 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
LIMIT SW LOAD SWDISPLAY MAIN
R802 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R803 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R804 1-208-437-41 RES,CHIP 1K 2% 1/10W
R805 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R806 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R807 1-208-445-41 RES,CHIP 2.2K 2% 1/10W
R808 1-208-449-41 RES,CHIP 3.3K 2% 1/10W
R809 1-208-453-41 RES,CHIP 4.7K 2% 1/10W
R810 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
R811 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R812 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R813 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R814 1-208-437-41 RES,CHIP 1K 2% 1/10W
R815 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R816 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R817 1-208-445-41 RES,CHIP 2.2K 2% 1/10W
R818 1-208-449-41 RES,CHIP 3.3K 2% 1/10W
R819 1-208-453-41 RES,CHIP 4.7K 2% 1/10W
R820 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
(C480)
R821 1-208-449-41 RES,CHIP 3.3K 2% 1/10W
(C480)
R822 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
(C480)
R823 1-208-518-41 RES,CHIP 22K 2% 1/10W
(C480)
R825 1-216-202-00 RES,CHIP 1.5K 5% 1/8W
(C580)
R831 1-216-025-00 RES,CHIP 100 5% 1/10W
R832 1-216-029-00 METAL CHIP 150 5% 1/10W
R833 1-216-025-00 RES,CHIP 100 5% 1/10W
R834 1-216-029-00 METAL CHIP 150 5% 1/10W
R835 1-216-025-00 RES,CHIP 100 5% 1/10W
R836 1-216-029-00 METAL CHIP 150 5% 1/10W
R837 1-216-025-00 RES,CHIP 100 5% 1/10W
R838 1-216-037-00 METAL CHIP 330 5% 1/10W
R839 1-216-025-00 RES,CHIP 100 5% 1/10W
R840 1-216-029-00 METAL CHIP 150 5% 1/10W
R841 1-216-025-00 RES,CHIP 100 5% 1/10W
R842 1-216-029-00 METAL CHIP 150 5% 1/10W
R843 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R844 1-216-202-00 RES,CHIP 1.5K 5% 1/8W
R845 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R848 1-216-049-11 RES,CHIP 1K 5% 1/10W
R849 1-216-049-11 RES,CHIP 1K 5% 1/10W
R850 1-216-049-11 RES,CHIP 1K 5% 1/10W
R851 1-216-107-00 RES,CHIP 270K 5% 1/10W
R852 1-216-121-00 RES,CHIP 1M 5% 1/10W
R853 1-216-049-11 RES,CHIP 1K 5% 1/10W
R854 1-216-198-00 RES,CHIP 1K 5% 1/8W
R855 1-216-198-00 RES,CHIP 1K 5% 1/8W
R856 1-216-198-00 RES,CHIP 1K 5% 1/8W
R857 1-216-025-00 RES,CHIP 100 5% 1/10W
R858 1-216-033-00 METAL CHIP 220 5% 1/10W
< ROTARY ENCODER >
RE801 1-475-014-11 ENCODER, ROTARY
< SWITCH >
S801 1-762-937-11 SWITCH, ROTARY (D-BASS) (C480)
S802 1-771-290-11 SWITCH, SLIDE (SEEK/AMS)
*************************************************************
* 1-659-835-12 LIMIT SW BOARD
***************
< SWITCH >
SW3 1-572-688-11 SWITCH, PUSH (1 KEY) (LIMIT)
*************************************************************
* 1-659-837-11 LOAD SW BOARD
**************
< SWITCH >
SW4 1-572-288-11 SWITCH, PUSH (DOWN)
*************************************************************
* A-3294-347-A MAIN BOARD, COMPLETE (C480:US,Canadian)
* A-3294-356-A MAIN BOARD, COMPLETE (C580)
* A-3294-383-A MAIN BOARD, COMPLETE (E)
*********************
* 3-019-529-01 HEAT SINK
* 3-019-533-01 BRACKET (REG)
* 3-019-565-01 BRACKET (IC)
7-685-547-14 SCREW +BTP 3X10 TYPE 2 N-S
7-685-793-09 SCREW +PTT 2.6X8 (S)
7-685-794-09 SCREW +PTT 2.6X10 (S)
< CAPACITOR >
C101 1-163-010-11 CERAMIC CHIP 0.0012uF 10% 50V
C103 1-164-346-11 CERAMIC CHIP 1uF 16V
C104 1-164-346-11 CERAMIC CHIP 1uF 16V
C105 1-164-809-11 CERAMIC CHIP 0.0047uF 10% 25V
C106 1-164-346-11 CERAMIC CHIP 1uF 16V
C107 1-126-160-11 ELECT 1uF 20% 50V
C108 1-126-160-11 ELECT 1uF 20% 50V
C109 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C110 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C111 1-126-157-11 ELECT 10uF 20% 16V
C112 1-164-492-11 CERAMIC CHIP 0.15uF 10% 16V
C113 1-164-492-11 CERAMIC CHIP 0.15uF 10% 16V
C114 1-126-157-11 ELECT 10uF 20% 16V
C115 1-124-234-00 ELECT 22uF 20% 16V
(C580)
C116 1-124-234-00 ELECT 22uF 20% 16V
(C580)
