Note on Schematic Diagram:
• All capacitors are in µF unless otherwise noted. pF: µµF
50 WV or less are not indicated except for electrolytics
and tantalums.
• All resistors are in Ω and
1
/
4
W or less unless otherwise
specified.
Note: The components identified by mark ! or dotted line
with mark ! are critical for safety.
Replace only with part number specified.
• U : B+ Line.
• H : adjustment for repair.
• Power voltage is dc 14.4V and fed with regulated dc power
supply from ACC and BATT cords.
• Voltage and waveforms are dc with respect to ground
under no-signal conditions.
no mark : CD PLAY
∗
: Impossible to measure
• Voltages are taken with a VOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal production
tolerances.
• Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal production
tolerances.
• Circled numbers refer to waveforms.
• Signal path.
J : CD
• Waveforms (MODE:PLAY)
1
2
3
4
5
6
7
Approx. 620mVp-p
IC2
1
(FEO)
0V
IC2
#¡
(RFO)
1.2Vp-p
Approx. 200mVp-p
IC2
$™
(TEO)
0V
IC1
3
(MDP)
2.6Vp-p
7.6µsec
IC1
@º
(LRCK)
5.8Vp-p
22.7µsec
IC1
@™
(BCK)
5.7Vp-p
474nsec
16.89MHz
IC1
#¢
(XTAI)
3.2Vp-p
w
w
