– 62 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
IC701 8-759-473-70 IC SM5852FS-E2
IC702 8-759-498-36 IC SM5878AM-E2
IC801 8-759-535-60 IC MB90574PFV-G-111
IC803 8-759-449-89 IC BA8270F-E2
IC901 8-759-347-50 IC BA3918-V3
IC902 8-749-010-99 IC KIA7039P-AT
< JUMPER RESISTOR >
JR1 1-216-295-00 SHORT 0
JR2 1-216-295-00 SHORT 0
JR124 1-216-295-00 SHORT 0 (C480)
JR125 1-216-295-00 SHORT 0 (C480)
JR224 1-216-295-00 SHORT 0 (C48O)
JR225 1-216-295-00 SHORT 0 (C480)
JR401 1-216-295-00 SHORT 0
JR402 1-216-295-00 SHORT 0
JR604 1-216-295-00 SHORT 0
JR605 1-216-295-00 SHORT 0
JR666 1-216-295-00 SHORT 0
JR701 1-216-295-00 SHORT 0
JR702 1-216-295-00 SHORT 0
JR705 1-216-295-00 SHORT 0
JR706 1-216-295-00 SHORT 0 (C580)
JR707 1-216-295-00 SHORT 0 (C580)
JR708 1-216-295-00 SHORT 0 (C580)
JR803 1-216-295-00 SHORT 0 (C580)
JR855 1-216-295-00 SHORT 0 (C580)
JR856 1-216-295-00 SHORT 0 (C580)
JR857 1-216-295-00 SHORT 0 (US,Canadian)
< COIL >
JW25 1-412-478-11 INDUCTOR, MICRO 0.15uH
(C480:US,Canadian)
JW25 1-414-137-31 INDUCTOR, MICRO 0.22uH (C580)
L201 1-414-137-31 INDUCTOR, MICRO 0.22uH
L601 1-410-513-11 INDUCTOR 22uH
L703 1-410-513-11 INDUCTOR 22uH
L801 1-410-501-11 INDUCTOR 2.2uH
L901 1-416-539-11 INDUCTOR 0uH
< JACK >
PJ400 1-764-804-11 JACK, PIN 6P (BUS AUDIO IN,
LINE OUT FRONT/REAR)
< TRANSISTOR >
Q110 8-729-920-21 TRANSISTOR DTC314TKH04
Q111 8-729-920-21 TRANSISTOR DTC314TKH04
Q210 8-729-920-21 TRANSISTOR DTC314TKH04
Q211 8-729-920-21 TRANSISTOR DTC314TKH04
Q401 8-729-901-05 TRANSISTOR DTA124EK
Q402 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q601 8-729-620-06 TRANSISTOR 2SC3052-EF
Q602 8-729-620-06 TRANSISTOR 2SC3052-EF
Q609 8-729-027-44 TRANSISTOR DTC114TK
Q611 8-729-021-94 TRANSISTOR 2SK1657-T1B
Q612 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q706 8-729-901-05 TRANSISTOR DTA124EK
Q801 8-729-620-06 TRANSISTOR 2SC3052-EF
Q901 8-729-901-05 TRANSISTOR DTA124EK
Q902 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q903 8-729-019-00 TRANSISTOR 2SD2394-G
Q905 8-729-422-27 TRANSISTOR 2SD601A-Q
Q906 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q907 8-729-901-05 TRANSISTOR DTA124EK
Q908 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q909 8-729-920-85 TRANSISTOR 2SD1664-QR
Q910 8-729-901-05 TRANSISTOR DTA124EK
Q911 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q912 8-729-019-00 TRANSISTOR 2SD2394-G
Q913 8-729-015-11 TRANSISTOR 2SD1802FAST-TL
Q914 8-729-901-05 TRANSISTOR DTA124EK
Q915 8-729-901-05 TRANSISTOR DTA124EK
Q916 8-729-620-06 TRANSISTOR 2SC3052-EF
< RESISTOR >
R101 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
(C480)
R101 1-216-084-00 METAL CHIP 30K 5% 1/10W
(C580)
R102 1-216-073-00 METAL CHIP 10K 5% 1/10W
R104 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R105 1-216-081-00 METAL CHIP 22K 5% 1/10W
(C580)
R106 1-216-081-00 METAL CHIP 22K 5% 1/10W
(C580)
R107 1-216-082-00 RES,CHIP 24K 5% 1/10W
(C580)
R108 1-216-689-11 RES,CHIP 39K 5% 1/10W
(C580)
R109 1-216-082-00 RES,CHIP 24K 5% 1/10W
(C580)
R110 1-216-689-11 RES,CHIP 39K 5% 1/10W
(C580)
R111 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R112 1-216-041-00 METAL CHIP 470 5% 1/10W
R113 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R114 1-216-041-00 METAL CHIP 470 5% 1/10W
R115 1-216-075-00 METAL CHIP 12K 5% 1/10W
R116 1-216-075-00 METAL CHIP 12K 5% 1/10W
R117 1-216-129-00 METAL CHIP 2.2M 5% 1/10W
R118 1-216-129-00 METAL CHIP 2.2M 5% 1/10W
R121 1-216-295-00 SHORT 0
R122 1-216-049-11 RES,CHIP 1K 5% 1/10W
(E)
R122 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
(C480:US,Canadian)
