CDX-GT55UIW/GT550UI/GT600UI
10
3-3. MAIN BOARD
3-4. SERVO BOARD
0 MAIN board
insulating sheet
3
2 two
screws
(+PTT 2.6
u
8)
8
screw
(+PTT 2.6
u
10)
4
screw
(+PTT 2.6
u
10)
9 heat sink
7 two
screws
(+P 2.6
u
8)
5 two
screws
(+P 2.6
u
8)
6 two
screws
(+PTT 2.6
u
10)
1 three ground point screws
(+PTT 2.6 u 6)
8 SERVO board
SERVO board
4 toothed lock screw
(M 1.7 u 2.5)
3 toothed lock screw
(M 1.7 u 2.5)
2 Remove the eleven solders.
7 optical pick-up (16 core)
(CN101)
5 claw
6 claw
gray
yellow
blue
orange
red
black
red
white
black
red
white
1 wire (flat type) (13 core)
(CN471)
