Sony CDX-GT637UI - CD Mechanism Section (MG-101 Z-188;;Q)

35
CDX-GT63UIW/GT630UI/GT637UI
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
101 A-1313-179-A MECHANICAL BLOCK (U) ASSY (08)
102 A-1284-705-A DAXEV08//Q
0 103 X-2149-672-1 SERVICE ASSY, OP (DAX-25A)
104 2-626-869-31 SCREW (M2X3), SERRATION
5-3. CD MECHANISM SECTION
(MG-101Z-188//Q)
105 3-686-458-11 SCREW (P1.4), TAPPING
106 3-352-758-31 SCREW (M1.7X2.5), TOOTHED LOCK
107 A-1554-409-A SERVO BOARD, COMPLETE
108 2-134-636-71 SCREW (M1.7X2.5)
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
101
102
108
108
103
105
104
107
106
106
