36
CDX-GT63UIW/GT630UI/GT637UI
SECTION 6
ELECTRICAL PARTS LIST
JACK BOARD
***********
< FERRITE BEAD >
FB901 1-414-760-21 INDUCTOR, FERRITE BEAD
FB902 1-414-760-21 INDUCTOR, FERRITE BEAD
FB903 1-414-760-21 INDUCTOR, FERRITE BEAD
< JACK >
J901 1-821-687-11 JACK, 3.5 SMALL TYPE (AUX)
*************************************************************
KEY BOARD
**********
1-780-433-11 CONDUCTIVE BOARD, CONNECTION
3-874-328-01 ILLUMINATOR (LCD)
< CAPACITOR >
C901 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C902 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C903 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C904 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C905 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C921 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C922 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C981 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C982 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C983 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C984 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C985 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C986 1-135-834-11 CERAMIC CHIP 2.2uF 6.3V
C991 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C992 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C993 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C999 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN901 1-818-141-11 PLUG, CONNECTOR 20P
CN971 1-820-858-31 CONNECTOR, USB (SOCKET) 6P (USB)
< DIODE >
D901 6-501-743-01 DIODE MAZ8068GMLS0
D902 6-501-743-01 DIODE MAZ8068GMLS0
D903 6-501-743-01 DIODE MAZ8068GMLS0
D904 6-501-743-01 DIODE MAZ8068GMLS0
D905 6-501-743-01 DIODE MAZ8068GMLS0
D906 6-501-782-01 DIODE MAZ8180GMLS0
D907 6-501-743-01 DIODE MAZ8068GMLS0
D908 6-501-743-01 DIODE MAZ8068GMLS0
D909 6-501-743-01 DIODE MAZ8068GMLS0
D910 6-501-743-01 DIODE MAZ8068GMLS0
D911 6-501-743-01 DIODE MAZ8068GMLS0
D971 6-501-743-01 DIODE MAZ8068GMLS0
D972 6-501-743-01 DIODE MAZ8068GMLS0
D975 6-501-743-01 DIODE MAZ8068GMLS0
D976 6-501-743-01 DIODE MAZ8068GMLS0
D977 8-719-058-24 DIODE RB501V-40TE-17
D978 6-501-817-01 DIODE MA2J1110GLS0
D979 6-501-743-01 DIODE MAZ8068GMLS0
D981 6-501-738-01 DIODE MAZ8062GMLS0
D982 6-501-817-01 DIODE MA2J1110GLS0
< IC >
IC971 6-703-107-01 IC SN74LVC2G66DCUR
IC981 6-707-064-01 IC LC75876WH-US-E
IC982 6-600-629-01 IC RS-470 (IR)
< COIL >
L921 1-457-223-11 COIL, COMMON MODE CHOKE
< LIQUID CRYSTAL DISPLAY >
LCD901 1-802-773-11 DISPLAY PANEL, LIQUID CRYSTAL
< DIODE >
LED901 6-502-542-01 LED SCM015BC7TT86P (OFF)
LED902 6-502-542-01 LED SCM015BC7TT86P ( (BROWSE))
LED903 6-502-542-01 LED SCM015BC7TT86P (ZAP)
LED904 6-502-542-01 LED SCM015BC7TT86P ( (BACK))
LED905 6-502-542-01 LED SCM015BC7TT86P (SEEK+/M >)
LED906 6-502-542-01 LED SCM015BC7TT86P (. m/SEEK–)
LED907 6-502-542-01 LED SCM015BC7TT86P (SOURCE)
LED908 6-502-542-01 LED SCM015BC7TT86P (MODE)
LED909 6-502-542-01 LED SCM015BC7TT86P (BTM/CAT) (US,CND)
LED909 6-502-542-01 LED SCM015BC7TT86P (AF/TA/PTY)
(EXCEPT US,CND)
LED910 6-502-542-01 LED SCM015BC7TT86P (1/ALBUM –)
LED911 6-502-542-01 LED SCM015BC7TT86P (2/ALBUM +)
LED912 6-502-542-01 LED SCM015BC7TT86P (3/REP)
LED913 6-502-542-01 LED SCM015BC7TT86P (4/SHUF)
LED914 6-502-542-01 LED SCM015BC7TT86P (5/DM+)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• CAPACITORS
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
CND : Canadian model
RU : Russian model
IT : Italian model
JACK
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifi é.
KEY
To Next Page
