Sony CDX-M800 - Location of Controls

4
Location of controls
Refer to the pages listed for details.
a SCRL (scroll) button 10
b DSPL/PTY (display mode change/
programme type) button 10, 12, 15, 18
c Number buttons
(1) REP 11
(2) SHUF 11
To store stations/receive stored stations.
d EQ7 button 22
e MENU button
To display the menus.
f SOURCE (Power on/Radio/CD/MD*
1
/
AUX*
2
) button
To select the source.
g SEEK (</,) buttons
To skip tracks/fast-forward, reverse a track/
tune in stations automatically, find a station
manually/select a setting.
h SOUND button 21
i OFF (Stop/Power off) button
6, 9, 22,
25
j VOL (+/–) buttons
To turn up or down the volume.
k OPEN/CLOSE button 9
l AF button 16, 17
m TA button 17
n MODE button
To change the operation.
o DSO button 23
p LIST button 12, 13, 15
q DISC (M/m) buttons
To receive preset stations/change the disc*
3
,
skip albums*
4
/select a menu.
r ENTER button
To enter a setting.
s ATT button 21
*1 When an optional MD unit is connected.
*2 Available only when an optional Sony portable
device is connected to BUS AUDIO IN of the unit.
You cannot connect any optional CD/MD units at
the same time.
*3 When an optional CD/MD unit is connected.
*4 Available only when an optional CD unit with the
MP3 file control function is connected, and an MP3
file is played.
Card remote commander RM-X111
DISC
–
ATTOFF
SCRL
DSPL
1
4
AF
MODE
2
5
TA
3
6
SOURCE
DISC
+
SEEK
+
SEEK
–
SOUND
ENTER
MENU
LIST
EQ7 DSO
VOL
+
–
OPEN/CLOSE
PTY
REP SHUF
DISC
–
SOURCE
DISC
+
SEEK
+
SEEK
–
(SEEK) (<):
to select
leftwards
(DISC) (M):
to select upwards
In menu mode, the currently selectable button(s) of
these four are indicated with a “ v” in the display.
(DISC) (m):
to select downwards
(SEEK) (,):
to select
rightwards
Note
If the display disappears by pressing (OFF), it cannot
be operated with the card remote commander unless
(SOURCE) on the unit is pressed, or a disc is inserted
to activate the unit first.
Tip
Refer to “Replacing the lithium battery” for details on
how to replace the batteries (page 26).
